VE-H extra clear/PVB film/ EVA film/EVA foil
  • Product Sort:PVB Film
  • Contact Person:Carol Chen
  • Location:Guangdong China
  • Post Time:2015/6/30
  • contact
  • VIP member
  • FOSHAN CHINA E&N FILM TECHNOLOGY CO., LTD
  • Company Mode:Manufactures
  • Tel:086-757-81181117
  • Fax:086-757-85583938
  • Add:Yanfeng Ningxi industrial Zone,Shishan Town,Nanhai District.Foshan City,Guangdong Province,China
  • Post Code:528231
  • E-mail:carol@en168.com
  • Website:http://www.en168.com
Detail Information:

VE-H high transparent EVA film --the best mechanical performance product with best formula and best material. Can be widely used in architectural safety glass, bullet-proof glass, anti-explosion glass etc.

Product specification:

0.40mm*2300mm*100m; 0.80mm*2300mm*50M;

0.40mm*2100mm*100m; 0.80mm*2100mm*50M;

Advanges:

1.Superior stability after breakage and High fracture integrity.

2.Cross-linking :85-95% (130-150°C)with good heat&humidty resistance.

3. Less overflowing: Milt index 5-6;

4. Superior water-proof: Open edge application

5. Better Sound insulation

6. Perfect sunlight control and UV filtering.

7. Crystalline particle control make EVA film more transparency and cleanliness.



Product Details:

1. The best mechanical performancet:
Cross-linking Extracted in Xylene solution >95%(after150°C25mins laminating)
Tensile strength >21MPA
Adhesion with glass >95N/cm
Water absorption <0.1%
2. Superior optical performance:
Light transmittance >91%
Haze <0.2%
UV filtering >99% (390nm wavelength)
Light transmittance decrease <0.5%( 2000hrs UV radiation)
Yellow index (YI) <3 (2000hrs UV radiation)
3. Best durability an stability in outdoor climate application: Heat and humidity resistance, Radiation resistance, ball impact peeling test and shot bag impact have been tested for laminated glass with norminal thickness according to GB15763.3-2009 safety glazing materials in building-Part3: Laminated glass.
Boilding test (2rhrs into 100°C water) 5mm glass+0.80mm EVA+5mm glass Good
Heat and Humidty resistance test 85°C 85%RH,1000hrs Good
Anti-aging test 50°C 65%RH,UV radiation 2000hrs Good
Heat and cold shock test -40°C30mins/80°C30mins, 50circles Good
Impact resistance against shot-bag GB-15763.3-2009 Qualified
Ball impact peeling resistance GB*15763.3-2009 Qualified

Laminating instructions:

1. Prepare and cut the EVA film into right size according to the following structure:

glass+EVA film + glass

2. Put the overlapped glass into silicon bag and seal silicon bag well.

3. Activate vacuum pump for 5-8min till vacuum value reach -0.095Mpa to double checking the vacuum is good.

4 Set up the laminating temp. and time and start heating.The following data based on 5mm glass +0.40mm EVA +5mm glass.

Heating speed

Temp. And holding time

Vacuum value

First section

2°C/ min

60°C

25mins

-0.095MPA

Second section

2°C/ min

80°C

30mins

-0.095MPA

Third section

2°C/ min

135°C

45mins

-0.04MPA

Remark: The above curves only for reference, the user should do some adjusts according to the process surroudings(temperature and humidity), glass area, glass thicknes,glass type and the machine itself.



Certificate:

SGS and ISO9001 and EN ISO 12543-4:1998 made by our agent
