Detail Information:
VE-H high transparent EVA film --the best mechanical performance product with best formula and best material. Can be widely used in architectural safety glass, bullet-proof glass, anti-explosion glass etc.
Product specification:
0.40mm*2300mm*100m; 0.80mm*2300mm*50M;
0.40mm*2100mm*100m; 0.80mm*2100mm*50M;
Advanges:
1.Superior stability after breakage and High fracture integrity.
2.Cross-linking :85-95% (130-150°C)with good heat&humidty resistance.
3. Less overflowing: Milt index 5-6;
4. Superior water-proof: Open edge application
5. Better Sound insulation
6. Perfect sunlight control and UV filtering.
7. Crystalline particle control make EVA film more transparency and cleanliness.
Product Details:
1. The best mechanical performancet:
Cross-linking |
Extracted in Xylene solution |
>95%(after150°C25mins laminating) |
Tensile strength |
|
>21MPA |
Adhesion with glass |
|
>95N/cm |
Water absorption |
|
<0.1% |
2. Superior optical performance:
Light transmittance |
>91% |
Haze |
<0.2% |
UV filtering |
>99% (390nm wavelength) |
Light transmittance decrease |
<0.5%( 2000hrs UV radiation) |
Yellow index (YI) |
<3 (2000hrs UV radiation) |
3. Best durability an stability in outdoor climate application: Heat and humidity resistance, Radiation resistance, ball impact peeling test and shot bag impact have been tested for laminated glass with norminal thickness according to GB15763.3-2009 safety glazing materials in building-Part3: Laminated glass.
Boilding test (2rhrs into 100°C water) |
5mm glass+0.80mm EVA+5mm glass |
Good |
Heat and Humidty resistance test |
85°C 85%RH,1000hrs |
Good |
Anti-aging test |
50°C 65%RH,UV radiation 2000hrs |
Good |
Heat and cold shock test |
-40°C30mins/80°C30mins, 50circles |
Good |
Impact resistance against shot-bag |
GB-15763.3-2009 |
Qualified |
Ball impact peeling resistance |
GB*15763.3-2009 |
Qualified |
Laminating instructions:
1. Prepare and cut the EVA film into right size according to the following structure:
glass+EVA film + glass
2. Put the overlapped glass into silicon bag and seal silicon bag well.
3. Activate vacuum pump for 5-8min till vacuum value reach -0.095Mpa to double checking the vacuum is good.
4 Set up the laminating temp. and time and start heating.The following data based on 5mm glass +0.40mm EVA +5mm glass.
|
Heating speed
|
Temp. And holding time
|
Vacuum value
|
First section
|
2°C/ min
|
60°C
|
25mins
|
-0.095MPA
|
Second section
|
2°C/ min
|
80°C
|
30mins
|
-0.095MPA
|
Third section
|
2°C/ min
|
135°C
|
45mins
|
-0.04MPA
|
Remark: The above curves only for reference, the user should do some adjusts according to the process surroudings(temperature and humidity), glass area, glass thicknes,glass type and the machine itself.
Certificate:
SGS and ISO9001 and EN ISO 12543-4:1998 made by our agent
