GX-P Series Horizontal Roller Hearth Flat Glass Tempering Furnace
  • Product Sort:Glass furnace
  • Contact Person:Tracy
  • Location:Henan China
  • Post Time:2016/8/2
  • contact
  • VIP member
  • LUOYANG GANGXIN GLASS TECHNOLOGY CO.,LTD
  • Company Mode:Manufactures+Trader
  • Tel:0086-379-63711055
  • Fax:0086-379-62201609
  • Add:NO.25, AIRPORT ROAD, LAOCHENG DISTRICT, LUOYANG, HENAN PROVINCE, CHINA
  • Post Code:4713000
  • E-mail:export01@lygangxinglass.com
  • Website:http://www.lygangxinglass.com/
Detail Information:

GX-P series flat glass tempering furnace are mainly used to produce flat tempered glass lor architectu ral purpose,interior decoration,furniture appliances,instrumentation,lamp,etc.

Glass sheet size:Max size 3500×12000(mm),Min size 60×60(mm);
High quality and product:Up to GB9963、GB9656、ECER43、ANSIZ97.1 standards;
Broad appliabity:FIoat glass,coated glass,rollde patterned glass;
Advanced heating methods:Radiation/convection matrix heating optional with intelligent  heating control system;
Lower energy wasting:Continue producing and tempering,reduce energy wasting;
Easy operation:User-friendly interface,whole produce with auto-control;
Full date storage:Computer-stored glass-type parameter recipes for full range of glass types.


GX-P Series Flat Glass Tempering Furnace Parameters

GX-QDLP Series Forced Convection Flat Glass Tempering Furnace Parametors

Model
Thickness Range(mm)
Max.Glass Size(mm)
Min.Glass Size(mm)
Productivity
Installed Power(KW)
GX-P0310
(3)4-8
300×1000
60×60
4
60
GX-P0609
(3)4-8
600×900
90×90
8
75
GX-P0820
(3)4-12
800×2000
120×120
23
300
GX-P0920
(3)4-12
900×2000
100×150
35
350
GX-P1220
(3)4-12
1250×2000
100×250
40
380
GX-P1225
(3)4-19
1250×2500
100×250
48
400
GX-P1236
(3)4-19
1250×3600
100×250
69
450
GX-P1525
(3)4-19
1500×2500
100×250
56
500
GX-P1536
(3)4-19
1500×3660
100×250
83
580
GX-(QDL)1725
(3)4-19
1700×2500
100×280
64(73)
450
GX-(QDL)1736
(3)4-19
1700×3660
100×280
94(108)
600
GX-(QDL)2025
4-19
2000×2500
100×280
85(97)
590
GX-(QDL)2036
4-19
2000×3660
100×280
110(126)
650
GX-(QDL)2436
4-19
2440×3660
100×300
134(154)
770
GX-(QDL)2442
4-19
2440×4200
100×300
153(175)
880
GX-(QDL)2450
4-19
2440×5000
100×300
183(210)
1032
GX-(QDL)2460
4-19
2440×6000
100×300
220(253)
1210
GX-(QDL)2480
5-19
2440×8000
100×300
293(336)
1470
GX-(QDL)2836
4-19
2850×3660
200×400
166(190)
920
GX-(QDL)2842
4-19
2850×4200
200×400
190(218)
1050
GX-(QDL)2850
5-19
2850×5000
200×400
220(253)
1100
GX-(QDL)P3360
5-19
3300×6000
200×400
350(402)
1500




Remarks:

1. Models out of the above ones can bemade according to client's requirements.

2. The output is calculated based on 100% loading rate of 5mm float glass,and 95% finished products rate Final cases depend on actual design.
3.Gangxin Glass reserves all rights of technical innovations and eliminations.
4.Thein stalled power and productivity may be alittle different fromthe actural case,it is just fortelerence.
5.GX-P Series Horizontal Roller Hearth Flat Glass Tempering Furnace isradiation heating merhod which can not produce the Low-E glass.
